MARK 3

Attribute:

Share



The Mark 3 Series offers high flow in a miniature valve design. The Mark 3 line is available with 10-32 or 1/8 porting in either sub-base or manifold mounting, sandwich speed control and sandwich pressure regulators.


Standard Specifications for Mark 3, SPA 3, and PA 3 Series Valve:

- Cv: 0.35

- Port Sizes: 1/8 NPTF & G, 10-32, M5

- 5 ported, 2 and 3 position, 4-way, spool & sleeve

- Flow Capacity: 8.34 to 16.21 SCFM @ 80 PSIG / 177 to 345 NI/m @ 6 bar

- Operating Pressure Range: 28" Hg. Vacuum to 150 PSIG / Vacuum to 10 bar

- Pilot Pressure Range: 20 to 100 PSIG / 2 Position Detented 15 to 100 PSIG

- Temperature Range (Ambient): -10°F to +115°F (-23°C to +46°C) / Air Pilot +200°F (+93°C)

Features for Mark 3, SPA 3, and PA 3 Series Valve:

- Direct solenoid, air pilot or solenoid air pilot actuated

- DIN plug-in solenoid with indicator light

- Unlubricated or lubricated service

- Integral speed control available

- Integral regulators available

- NEMA 4/IP65


HOWTO ORDER
